Acrylic (56206)

Acrylic (56206)

Category : Acrylic / Polyback

WIDE RANGE OF LATTE ACRYLIC / POLYBACK BOARDS COLORS & SHAPES WOOD TEXTURE, PATTERNS & SOLID COLORS

AVAILABLE IN 1220x2440 MM

AVAILABLE - AS PER REQUEST -  ON MDF

LATTE ACRYLIC / POLYBACK SURFACE TECHNICAL SPECIFICATIONS

ACRYLIC SURFACE CHARACTERISTICS TEST METHOD UNIT VALUE

PHYSICAL PROPERTIES
Density ISO 1183-1 g/cm3 1,07-1,11

MECHANICAL PROPERTIES
Scratch resistance  DIN 68861/T4 N 1,2
Pencil Test  Visual  6H
EN 15186:2012 Class B
Abrasion resistance DIN 53754 mg/100U/min  6
EN 15186:2012 Class B
Resistance of surface to mechanical damage DIN 53799/T4.4.2 mm 7
Crosscut ISO 2409:2013   1
Impact small ball BS 3962: part 6: 1980 Class B

THERMAL PROPERTIES
Resistance to dry heat  DIN 68861/T7  ºC 100
EN 12722 : 2013 LEVEL 5
Resistance to wet heat  DIN 68861/T8 ºC  100
EN 12721:2013 LEVEL 5

OPTICAL PROPERTIES
Top surface gloss  DIN 67530 GLE >85
Color fastness ISO 4892-2    1,7

BURNING BEHAVIOUR
Flammability UL94   HB

OTHER PROPERTIES
Chemical resistance  DIN 68861/T1    No changes
Thermoforming temperature range    ºC 180-190
Behaviour to water vapour DIN 53799/T4.11   No changes

Polyback SURFACE CHARACTERISTICS TEST METHOD UNIT VALUE

MECHANICAL PROPERTIES
Scratch resistance  EN 15186:2012 Class B
Abrasion resistance EN 15186:2012 Class A
Crosscut ISO 2409:2013   1
Impact small ball BS 3962: part 6: 1980 Class B

THERMAL PROPERTIES
Resistance to dry heat  EN 12722 : 2013 LEVEL 5
Resistance to wet heat  EN 12721:2013 LEVEL 5

  • code : Acrylic (56206)
  • size : 1220X2440 mm
  • Thickness : 18 mm
